Product Overview
Technical Specifications
Quick Rigging Connector User Instructions >
Designed specifically for material handling and rigging
- Model #: 102105
- Description: QRC
- Length (in): 4.61"
- Width (in): 2.91"
- Gate (in): 1”
- Length (mm): 117
- Width (mm): 73.9
- Gate (mm): 25.4
- Weight (oz): 9
- Weight (g): 254.7
- SWL: 500
Description
QRC COPY:
Designed and manufactured in the U.S. for specialized material handling and rigging applications, the Harken Light Alloy Quick Rigging Connector (QRC) is quicker and easier to install than traditional shackles. The double-action, locking QRC can eliminate the hazard of dropped shackle pins, has a Safe Working Load (SWL) of 500 pounds and a design safety factor of 7:1. The Harken QRC is constructed of zinc plated Chromoly steel for strength and corrosion resistance. The QRC has a 1" gate opening and is stamped for Material Handling Only.
Not to be used as PPE for life safety applications.
